ICT Billet LS Camaro Low Mount Alternator, Power Steering Pump Brackets LSX LS1 LS6 Billet
LS1 Camaro Alternator and Power Steering Pump Bracket Kit
- Requires: 1998-02 LS1 Camaro (GTO any year) crank pulley (12553118)
- Requires: 1998-02 LS1 Camaro power steering pump & pulley (63105 & 12559885)
- Alternator: (19244779)(will not fit Corvette/CTSV/G8 or 2010 up Camaro large bolt pattern alternators), will fit any other LS powered vehicle alternators with any amperage. 145+ alternators do not have the provision for the rear bracket.
- Made in Wichita, KS from aerospace grade, USA billet aluminum
- Includes: alternator bracket, power steering bracket, idler pulley, and mouting hardware
- **Fits: all GM LS series engines
**On "truck" engine blocks with only 1 mounting hole in the block, you will be required to drill a second mounting hole using drill template 551445
Requires: 955K6 (95.5 inch) belt with 105 amp alternator and ICT Billet 551472-2 Sanden 7176 A/C kit
987K6 (98.7 inch) belt with 105 amp alternator and ICT Billet 551474-2 Sanden 508 A/C kit
895K6 (89.5 inch) belt with 105 amp alternator and ICT Billet 551495-2 R4 A/C kit
790K6 (79.0 inch) belt with 105 amp alternator and factory belt tensioner
980K6 (98.0 inch) belt with 105 amp alternator and ICT Billet 551585X-2 R4 A/C HD kit
These brackets mounts the power steering pump and alternator in the 98-02 Camaro Z28 Factory Location
$189.99
